DESCRIPTION

Output
• Output power capacity:900 Watts / 1.5 kVA
• Max Configurable Power (Watts):900 Watts / 1.5 kVA
• Nominal Output Voltage: 230V
• Output Voltage Distortion: Less than 5% at full load
• Output Frequency (sync to mains): 57 - 63 Hz for 60 Hz nominal
• Topology: Line Interactive
• Waveform type: Sine wave
• Output Connections: (8) IEC 320 C13 (Battery Backup)
• Transfer Time: 2ms typical

Input
• Nominal Input Voltage: 230V
• Input frequency: 50/60 Hz +/- 3 Hz (auto sensing)
• Input Connections: IEC-320 C14
• Input voltage range for main operations: 180 - 287 V
• Input voltage adjustable range for mains operation: 170 - 300 V
• Number of Power Cords: 1
• Other Input Voltages: 220, 240

Batteries & Runtime
• Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof
• Typical recharge time: 3 hour(s)
• Replacement Battery: APCRBC132
• RBC Quantity: 1
• Battery Volt-Amp-Hour Capacity: 260
• Runtime: View Runtime Graph View Runtime Chart

Communications & Management
• Interface Port(s): USB
• Control panel: Multi-function LCD status and control console
• Audible Alarm: Alarm when on battery: distinctive low battery alarm: configurable delays
• Emergency Power Off (EPO): --

Surge Protection and Filtering
• Surge energy rating: 459 Joules
• Filtering: Full time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449

Physical
• Maximum Height: 89, 8.9 cm
• Maximum Width: 432, 43.2 cm
• Maximum Depth: 457, 45.7 cm
• Rack Height: 2 U
• Net Weight: 28.64 kg
• Color: Black

Operating Temperature
• Operating Environment: 0 - 40 °C
• Operating Relative Humidity: 0 - 95 %
• Operating Elevation: 0-3000 meters
• Storage Temperature: -15 - 45 °C
• Storage Relative Humidity: 0 - 95 %
• Storage Elevation: 0-15000 meters
• Audibl
