APC Back-UPS ConnectCP12036LI

Reliable and affordable power protection for networking devices

Introducing APC Back-UPS™ Connect - an uninterruptible power supply (UPS) designed specifically to power compatible routers/modems, VoIP systems and other smart home devices during a power outage.

The new Back-UPS Connect is a reliable, flexible and affordable 12V DC UPS with lithium-ion battery ensuring service continuity for connected equipment during power outages.

That’s Certainty in a Connected World.

Why Do You Need a UPS?

Because Life Always Needs to be On.
Provide an emergency power supply for your electrical equipment to protect your investment from unexpected power disruption, including spikes, surges and voltage dips.

How does a UPS protect my uptime?

Power Surge Protection: Stabilises the main electrical line voltage to your devices.
Refined Power Supply: Protects connected devices from dips and spikes caused by lightning.
Instant Power: Power to your equipment the exact moment the power goes out, protecting you from data loss or unexpected interruption.

Ensure reliable uptime and clean power for your critical devices.



Why choose APC Back-UPS Connect?

Ensure that your equipment remains powered, protected and available in any scenario. Designed to keep your network devices such as routers, smart home assistants connected and online during power outages.

Additional Features



DC Input/Output

Designed to support various 12 Vdc (2.5mm default DC tip) networking applications such as modems and routers.



Long Runtime

Up to 4 hours of runtime for an average router to ensure reliable connectivity.



Multiple DC Tips

Comes with 2 additional pair of DC tips (2.1mm and 1.7mm) to ensure compatibility with different brands of networking gear with 12V rating.



Lithium-ion Battery

Provides significantly longer service life than traditional VRLA battery.



Compact Design

Small footprint for easy installation in tight spaces.



LED Indicators

Easy to read indicators providing battery capacity information.

Easily Setup Your APC Back-UPS Connect


Step 1.

Disconnect the power adapter from your 12V connected device.


Step 2.

Connect the power adapter of your 12V connected device to the input port of APC device.


Step 3.

Using the attached wire provided with the APC device, connect the APC device to your 12V connected device.


Step 4.

To turn on the APC device, press and hold the power button for 2 seconds.



Technical Specifications

Input

Nominal input voltage

12 Vdc

Input voltage range

11.4 - 12.6 Vdc

Input current

4.1 A (max)

Input over current protection

15 A fuse (fast acting fuse)

Output

Nominal output voltage

12 Vdc

Output current

0 - 3 A

Transfer time

0 ms @ 3 A load

Input/Output Configuration

Input connector

Barrel - center pin 2.5 mm; 5525 DC jack (default)

Output cable length

80 cm

Output connector

Barrel - center pin 2.5 mm; 5525 DC jack (default)

Additional DC tips

2.1 mm and 1.7 mm

Battery and Runtime

Battery type

Lithium-ion

Battery pack capacity

27.75 Wh

Runtime estimates

5W: 240 mins
6W: 200 mins
9W: 120 mins
20W: 60 mins
29W: 45 mins
36W: 30 mins

Typical recharge time

12 hours

User Interface

Display

LED indicators (power and battery level)

Power button LED

Bi-color red and green LED

Capacity indicator

4 green LEDs (each LED represents 25%)

Physical

Dimensions (W x H x D)

99 x 25 x 109mm

Net weight

0.3 kg

Environment

Operating temperature

0°C to 40°C

Operating humidity

0 to 90% non-condensing

Operating elevation

0 to 5,000 m at 100% load

Audible noise

<40 dB

Protection class

IP 20

Conformance

Certifications

CE, UKCA, KC, RCM, LVD, EMC, IEC/EN 62368-1, EN 55032 class B, EN 55035, EN 61000-3-2, EN 61000-3-3, MSDS, UN38.3, FCC part 15 Class B, RoHS3

Standard warranty

2 years
