Output
• Output power capacity:300 Watts / 500 VA
• Max Configurable Power (Watts):300 Watts / 500 VA
• Nominal Output Voltage:230V
• Output Frequency (sync to mains):47 - 63 Hz
• Output Frequency (not synced):50/60 Hz +/-1 Hz
• Topology:Standby
• Waveform type:Stepped approximation to a sinewave
• Output Connections:
◦ (1) IEC 320 C13 (selector_surgetitle)
◦ (3) IEC 320 C13 (Battery Backup)

• Transfer Time:6ms typical: 10ms maximum

Input
• Nominal Input Voltage:230V
• Input frequency:50/60 Hz +/- 3 Hz (auto sensing)
• Input Connections: IEC-320-C14 inlet Cord Length 1.83 meters
• Input voltage range for main operations:180 - 266 V
• Input voltage adjustable range for mains operation:160 - 300 V
• Number of Power Cords: 2
• Maximum Input Current:7.0 A

Batteries & Runtime
• Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof
• Typical recharge time:8 hour(s)
• Replacement Battery: RBC2
• RBC Quantity:1
• Battery Volt-Amp-Hour Capacity:83
• Runtime: View Runtime Graph View Runtime Chart
• Efficiency: View Efficiency Graph

Communications & Management
• Interface Port(s): Optional Simple Signalling RS232 cable, USB
• Control panel:LED status display with On Line: On Battery: Replace Battery and Overload indicators
• Audible Alarm: Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm

Surge Protection and Filtering
• Surge energy rating:310 Joules
• Data Line Protection: Analog phone line for phone/fax/modem/DSL (RJ-45 connector)
• Filtering:Full time multi-pole noise filtering: 5% IEEE surge let-through: zero clamping response time: meets UL 1449
